| DC | 45KW |
| Reducer | NGW61 |
| Speed rate | 1:8 |
| Sawing motor | 90KW, TWO POLE |
| Blade size | 900×120×5.0 |
| Electrical control | Sizing system: HDM-2019A type high-precision sizing computer; Touch screen interface |
| DC governor: Continental governor, 9 series 590c, 180A | |
| Low voltage electrical: using Schneider low voltage components, and one independent operation platform | |
| Sawing motor control: direct start control sawing motor | |
| Encoder: Omron encoder, 1000p, two pieces | |
| Proximity switches: 5 each for 3020c and 3008c | |
| Working parameters: fixed length, 3-25m. The sizing accuracy is 6000 ± 3mm. Production line speed 0-80m / min | |
| Mechanical part | Guide rail diameter: diameter 90, material GCr; process, high frequency quenching |
| Transmission parts: gear 28 teeth; module 6; width 90; rack length 3000; width 100; material 40Cr | |
| Saw structure: the saw-box structure is fully welded, the thickness of saw panel is 20mm, and the thickness of lining plate is 10mm. Liner spacing shall not exceed 240mm. Element bit thickness 40. The distance between trolley wheels shall not be less than 1000mm, and the length of trolley shall not be less than 1200mm. After welding, the whole trolley is annealed and then processed. Strengthen the position of cylinder seat. Add spring anti holding wheel. The outside width of the saw cover shall not be less than 260, and the inside shall be treated with sound absorption | |
| Saw arm part: saw arm support is added with locating pin, bearing is used for the pulling part between air cylinder and saw head, and the position of steel rod is adjustable | |
| Rack installation mode: the rack is suspended in the middle, and the gearbox is under the saw truck | |
| Bed design: I-beam design and foundation bolt installation. Total length of bed: 5500mm |
